Flat Roof Ballasted Solar Racking System (One Sides)

Flat roof ballasted solar racking systems are low-cost and easy to install PV modules. The system can also be used on the ground. The racking system has pallets underneath the panels on which heavy concrete blocks will be placed. The weight of these blocks keeps the solar panels on the flat roof.

The weight of rocks or concrete blocks is used in ballasted systems to resist wind uplift and seismic shaking forces acting on the solar array. Ballasted systems typically consist of interconnected rows and columns capable of (partially) transferring point loads from one module to multiple neighboring parts.

The MRac PV ballast system is a non-penetrating mounting system that will not leak or cause other problems and can also be adjusted to be fixed to the roof as needed. The ballast system mounting kit is compatible with all 60 or 72 standard solar panels and is also suitable for most other panels.

Flat roof ballasted solar racking can be designed with a fixed angle or adjustable brackets to meet the customer’s needs. They can be installed directly on the concrete rooftop or on blocks. Extruded aluminum solar mounting kits are highly pre-assembled to simplify installation, saving labor time and cost.

Product Application Examples

Application example of flat roof ballasted solar racking system


Built To Last

It is well-designed, which greatly simplifies installation and maximizes the use of available roof space.

Easy and Fast Installation

Pre-assembled brackets are simple and firm to install, and simple bolt fastening, saving project installation time.

Great Compatibility

The ballasted mounting system is compatible with most framed solar modules and allows for flexible array arrangement to maximize power generation and accommodate rooftop facilities (air-con units, lights, etc.).

High Quality

Mibet employs strict quality management and control over raw material procurement and the manufacturing process to ensure the delivery of high-quality products.

Flat Roof Ballasted Solar Racking System Details

Bracket details

Flat Roof Ballasted Solar Racking System Details
Flat Roof Ballasted Solar Racking System Details

Technical Parameter

TypeFlat roof, ground
Bottom SupportConcrete foundation
Installation Angle10°
Wind Load60m/s
Snow Load1.6KN/㎡
Panel Framingframed
Panel Orientationhorizontal
Design StandardsAS/NZS 1170, DIN 1055, JIS C8955:2017,
 International Building Code: IBC 2009,
 California Building Code: CBC 2010;
Bracket MaterialAL6005-T5 (surface anodized)
Fastener MaterialZinc-nickel alloy & SUS304
Parts MaterialAL6005-T5 (surface anodized)
Bracket ColorNatural or Customized
Warranty10 years
